Cisco 40g To 10g Breakout Cable Configuration

They would install the fet 40g in the uplinks of nexus c2348 and then install the fet 10g to the parent switch.

Cisco 40g to 10g breakout cable configuration.

You can break out the single 40g port into 4 separate 10g ports and use a qsfp to 4 lc breakout cable to connect one or more of the 10g ports to the 7706. The command splits each of the switch s 40g ports into four 10g ports breakout ports or each of the switch s 100g ports into four 25g ports or two 50g ports. We are testing 40g to 4x10g by using breakout cable from nexus and connect to crs. The port range is from 1 to 32.

40g to 4x10g breakout ports. And each fiber cable transmits at 10gbps. The 40g to 4 x 10g breakout will be based on qsfp optics. 100g to 4x25g breakout ports.

They would then have to buy a mpo breakout cable like mpo to 4 x sfp lc for a third party vendor. The cisco nexus 3232c switch supports breakout interfaces. Use the interface breakout module 1 port x map 10g 4x command. Interface breakout slot slot port port range map 10g 4x.

You have to enter the following command to enable the 10g breakout of the 40g port though. Interface breakout module 1 port x map 10g 4x 25g 4x 50g 2x nexus 3264q. The fet 10g is only supported in the uplink ports if it s used with the cvr qsfp sfp10g as adapter. Enables the breakout of 100g ports into 4 x 25g ports.

Mtp to 4x lc breakout cable is composed of an 8 fiber mtp connector for 40g qsfp at one end and 4 duplex lc connectors for 10g sfp at the other end. Bgp flowspec implementation on cisco 8000 platforms. Enables the breakout of 40g ports into 4 x 10g ports.
